Steel structure carport is a carport that uses steel structure as the main support and construction material. It has many advantages and application scenarios.
Steel structure carport is a carport that uses steel structure as the main support and construction material. It has many advantages and application scenarios:
1. Stable structure: Steel structure has high strength and rigidity, can withstand large loads, and ensure the structural stability of the carport.
2. Good durability: Steel structure has good corrosion resistance and durability, can adapt to various harsh environments, and extend the service life of the carport.
3. Fast construction speed: Steel structure components can be prefabricated in the factory and assembled on site, which greatly shortens the construction period.
4. High space utilization: Steel structure carport can be flexibly designed according to actual needs to achieve efficient space utilization.
Steel structure carport is widely used in various industrial plants, warehouses, garages and other places. Especially in places where large spans and heavy loads are required, it is the first choice.
1. Steel plate thickness: According to different design requirements and load requirements, the thickness of the steel plate is generally between 2mm and 30mm. There are also product steel plate thickness ranges including 5mm to 30mm, 6mm to 100mm, 5mm to 50mm, 8mm to 22mm and 5mm to 8mm.
2. Steel model: Commonly used steel models include Q235, Q355, etc. These steels have good mechanical properties and welding properties. Among them, Q235 steel has good plasticity and toughness, easy to process and weld; Q355 steel has higher strength and toughness, suitable for places with large loads.
3. Style and shape: The styles and shapes of steel structure parking houses are varied, including rectangular, circular, etc. Users can choose and design according to actual needs.
IV. Price and supplier
The price of Liweiyuan steel structure parking house varies depending on factors such as materials, design, and construction difficulty. Steel structure parking houses of different specifications and configurations can be provided to meet the needs of different users. Users can choose according to their own needs and budget. When purchasing, it is recommended that users communicate in detail with the Liweiyuan steel structure manufacturer to understand product performance, price, after-sales service and other information in order to make wise decisions.
Main materials for steel structure carport building
Item Material Material details
Steel frame
H-shaped steel column and beam Q355B steel, painted or galvanized
Crane beam Q355B steel, painted or galvanized
Secondary support Roof purlin Q235B C/Z steel galvanized
Wall purlin Q235B C/Z steel galvanized
Tie clip Q235, φ89*3 round steel pipe
Knee bracket Angle steel, Q235, L50*4
Roof horizontal support φ20, Q235B steel bar, painted or galvanized
Column vertical support φ20, Q235B steel bar, painted or galvanized
Casing φ32*2.0, Q235 steel pipe
Tie rod Φ10 round steel Q235
Roof and wall
Protection system Wall and roof panels Corrugated steel plate/sandwich panel
Gutter Color steel plate/Galvanized steel plate/Stainless steel
Trim and flash Color steel plate
Downspout PVC
Self-tapping screws
Fasteners system Anchor bolt Q235 steel
High-strength bolts Its specifications are determined according to the steel structure design.
Ordinary bolts
Nuts
Windows and doors Windows Aluminum windows
Doors Choose according to requirements, can be EPS doors, windproof doors, high-speed rolling doors, industrial sliding doors, etc.
Crane/Crane 3T/5T/10T/20T crane can be configured according to customer needs
If you are interested in our products, please let us know the following information so that we can design.
1. Purpose: garage, warehouse, workshop, showroom, etc.
2. Location: In which country will it be built?
3. Local climate: wind speed, snow load (maximum wind speed)
4. Size: length*width*height
